Our R&D team consists of 15 experienced design engineers, with lead engineers having over 30 years of expertise behind them. We are also able to apply for the various safety certifications required.
1. Input Voltage Range: 90~264VAC
2. AC Input Frequency Range: 47~63 Hz
3. Input Amps(Max): 3.7Amps RMS
4. Output Voltage: 12V/24V/48V
5. Output Max charge current(Imax): 10Amps
6. Rechargerable battery types: FLA, GEL, AGM, NiCad
7. Short circuit current: 6.25Amps
8. Charger fuse(external): 15 Amp ATO 32V blade fuse
9. Operating temperature: -10-70℃
10.Storage temperature: -20~85℃
11.MTBF: 500,000 hours
12.Maximum Efficiency : ≥89%
13.CANBUS Communications: 10 pin Molex connector 19428-0007(CAN communications)
